Behringer HA8000 V2 8-channel Headphone Mixing/Distribution Amplifier

Behringer HA8000 V2 8-Channel Headphone Amplifier Overview

The Behringer HA8000 V2 8-Channel Headphone Amplifier is a professional grade amplifier designed to deliver true sonic quality with every type of headphone. With 2 x stereo main inputs for 2 independent mixes and 8 x direct inputs, the HA8000 V2 offers users a wealth of options.

The 2 independent mixes are available on each of the 8 channels as well as an output level control and precise 8-digit LED output metre. Connection of any sound source is made easy with direct input connectors on each channel along with 1 front and 1 rear TRS phones connector per channel. A switching power supply ensures noise-free audio, superior transient response plus low power consumption.

Full Description

Features

• Professional, multi-purpose headphones amplifier system for stage & studio applications
• Highest sonic quality with virtually all types of headphones even at maximum volume
• 8 totally independent stereo high-power amplifier sections in one rack space
• 2 stereo main inputs for two independent mixes, accessible from all 8 output channels
• 8 independent direct inputs provide up to 8 individual stereo mixes
• Output level control & accurate 8-digit LED output metre per channel
• Mono/stereo switch per channel for more flexibility
• 1 front & 1 rear TRS phones connector per channel
• Direct input connector on each channel for easy connection of any sound source
• Parallel main outputs allow cascading of several headphones amplifiers
• Switching power supply

Specifications

• Main Inputs: 2 x XLR, 2 x 1/4'' TRS, Servo-Balanced
  • Impedance: 40kΩ Balanced, 20kΩ Unbalanced
  • Max Input Level: +22 dBu
  • CMMR: > 50 dB
• AUX In: 1 x 1/4'' TRS, Stereo
  • Impedance: 20kΩ
  • Max Input Level: +22 dBu
• Direct Input: 1 x 1/4'' TRS, Stereo
  • Impedance: 10kΩ
  Main Outputs: 2 x XLR Balanced, 2 x 1/4'' TRS Balanced
• Phones Output: 6 x 1/4'' TRS, Stereo
  • Max Output Level: +26 dBm @ 100Ω, +19 dBm @ 8Ω
  • Min Impedance: 8Ω
• System Specifications
  • Frequency Response: 10Hz to 90kHz, ±3 dB
  • Signal-To-Noise: >87 dB @ 0 dBu (22Hz to 22kHz)
  • Dynamic Range: 101 dB (22Hz to 22kHz)
  • Distortion (THD): 0.007 Percent Typ. @ +4 dBu (1kHz, Gain 1)
• Function Controls
  • Input Level: Variable
  • Balance (Per Channel): AUX (Left) / Main (Right), Variable
  • Output Level (Per Channel): Variable
  • Treble: ±12 dB @ 12kHz
  • Bass: ±12 dB @ 80Hz
• Function Switches
  • Mono L / R: Selectable
• Indicators
  • Input Level: -30, -24, -18, -12, -6, -3, 0 dB, Clip
  • Output Level: -30, -24, -18, -12, -6, -3, 0 dB, Clip
• Power
  • Switch Mode Power Supply: Autorange, 100-240V, 50/60Hz
  • Power Consumption: 35W
  • Main Connection: Standard IEC Receptacle
• Weight: 2 kg
• Dimensions
  • Height: 44 mm
  • Width: 483 mm
  • Depth: 149 mm
