Audio Technica ATM230 Hypercardioid Dynamic Instrument Microphone

The Audio-Technica ATM230 is a hypercardioid dynamic instrument microphone made for capturing drums and percussion. The mic's proprietary capsule is designed to excel in high-SPL applications, delivering full, well-rounded audio with accurate low-end reproduction.

The hypercardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of the desired sound source. It also sports a low-profile design which allows for a wide variety of placements. The ATM230 is ideally suited for miking toms, snares, and other percussion instruments.

• Hypercardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source
• Handles high SPL at close range
• Big, warm low-frequency response with accurate attack
• Low-profile design permits versatile placement around drum kit
• Rare earth magnet for improved output and transient response
• Rugged, all-metal design and construction
• Includes AT8665 drum mount and a soft protective pouch






  In the Box

  • Audio-Technica ATM230 Hypercardioid Dynamic Instrument Microphone
  • Audio-Technica Drum Microphone Clamp AT8665
  • Soft Protective Pouch








  Microphones
  Element	Dynamic
  Polar Pattern	Hypercardioid
  Frequency Response	30-12,000 Hz
  Open Circuit Sensitivity	-54 dB (1.9 mV) re 1V at 1 Pa
  Weight	292 g (10.3 oz)
  Dimensions	82.5 mm (3.2") long, 38.0 mm (1.5") maximum diameter
  Output Connector	Integral 3-pin XLRM-type
  Accessories Included	AT8665 drum mount for 5/8"-27 threaded adaptor; 5/8"-27 to 3/8"-16 threaded adaptor; soft protective pouch
  Audio-Technica Case Style	R2
