Move the dance floor with eight analog drum voices
Loaded with true analog circuitry, the Behringer RD-6 drum machine delivers drum sounds with amazing punch and depth. Just like the original, you have eight sounds to create your grooves — bass drum, snare drum, low and high toms, cymbal, clap, and open and closed hi-hats. Global Tone and Distortion controls allow to you dial in just the right amount of brightness and bite.
Craft full songs with pattern chaining
For on-the-fly experimentation, the RD-6 drum machine allows you to seamlessly switch between 32 patterns in real time. And when you're ready to start arranging complete tracks, you'll be able to chain patterns together for full songs up to 250 bars long. And if you prefer external sequencing, Sweetwater is pleased to report the RD-6 supports USB and MIDI control too.
Behringer RD-6 Analog Drum Machine Features:
Re-creation of the classic 606 analog drum machine
8 analog drum voices include bass drum, snare drum, low and high toms, cymbal, clap, and open and closed hi-hats
Create grooves with the 16-step sequencer, and switch seamlessly between up to 32 patterns on the fly
Compose full tracks by chaining patterns (up to 250 bars long)
Global Distortion effect adds bite and punch to your drum sounds
Immediate hands-on control thanks to 11 controls and 26 switches
2 x trigger outputs for controlling Eurorack or semi-modular synthesizers
Ready for any modern workflow, with sync options including USB, MIDI, Clock, or internal
Specifications
Drum Sounds: 8
Circuitry: Analog
Power Input: DC input connector
Power Switch: Push button on/of
USB (MIDI): USB 2.0, type B
MIDI In, Out / Thru: 2 x 5-pin DIN
Start / Stop: 1 x 1/4" TS
Mix Out: 1 x 1/4" TS, unbalanced, 1 k ohms impedance
Voice Output: 6 x 1/8" TS, unbalanced, 100 ohms impedance
Sync In / Out: 2 x 1/8" TRS (Tip is clock and Ring is the start message) more than: 2.5 V
Trigger Outs: LT and HT 2 x +15 V, 1PPS/24PPQ/48PPQ 50 pulse length, 2PPQ narrow pulse length.
Phones: 1 x 1/8" TRS, stereo, 15 ohms impedance
USB: Class compliant USB 2.0, type B
Supported Operating Systems: Windows 7 or higher Mac OS X 10.6.8 or higher
Pattern Capacity: 2 x 16 patterns
Steps: 16 steps
External Power Adapter: 9 V DC, 670 mA
Power Consumption: 2 W max
Indicator: Power LED
Operating Temperature Range: 5°C – 40°C (41°F – 104°F)
Dimensions (H x W x D): 56 x 305 x 165 mm (2.2 x 12 x 6.5")
Weight: 0.9 kg (2.0 lbs)
Shipping Weight: 1.6 kg (3.5 lbs)
Product Code: RD-6-TR
