effortlessly achieve premium-quality sound, thanks to 16 of our studio-grade XENYX Mic Preamps, 2 full stereo channels with 4-band EQ, plus 2 additional sets of stereo inputs channels with Level and Aux controls. All mono channels feature our ultramusical, 3-band “British” channel EQs, complete with a semi-parametric mid band for the ultimate in sound sculpting. Add to this not one, but two of our 24-bit dual-engine stereo FX processors with 99 awesome presets including reverb, chorus, flanger, delay, pitch shifter and various multi-effects – and the SX2442FX becomes an incredibly versatile mixer for your recording projects and live performances.
The SX2442FX features our legendary, high headroom XENYX mic preamps, which have been praised by audio engineers all over the world. These state-of-the-art mic pres represent a major step in the evolution of audio technology – and they can easily hold their own, even when compared to the most expensive stand-alone mic preamps. XENYX preamps offer a staggering 130 dB of dynamic range, with a bandwidth that extends from below 10 Hz to well above 200 kHz. Armed with these outstanding mic preamps, the SX2442FX provides such transparent, crystal-clear performance you just might think someone upgraded your mics while you weren’t looking.
| Total # Of Inputs | 24 |
| Mic/Line Inputs | 16 - XLR Microphone 24 - 1/4" TRS Phone Line |
| Stereo Line Inputs | 4 - 1/4" TRS Stereo Line |
| In-Line Inputs/Returns | No |
| AUX Sends | 2 AUX Sends - 1/4" TRS Phone 2 FX Sends - 1/4" TRS Phone |
| AUX Returns | 2 AUX Returns - L/R 1/4" TRS Phone |
| Inserts | 16 - 1/4" TRS Phone (mono inputs) 2 - 1/4" TRS Phone (main output) |
| BUS (Group) Outputs | 4 - 1/4" TRS Phone |
| 2 Trk Master I/O | Main Out - Stereo L/R 3-pin XLR Main Out - Stereo L/R 1/4" TRS Phone Mono Out - 1/4" Phone Phono/CTRL Room - Stereo Single 1/4" TRS Phone |
| ALT I/O | Foot Switch - 1/4" Phone |
| Monitor Outputs | Phono/CTRL Room - Stereo Single 1/4" TRS Phone |
| AEQ Section | Mono Channels Low - 80Hz +/- 15dB Mid - 100Hz to 8kHz +/- 15dB High - 12kHz +/- 15dB Low Cut - 80Hz, 18dB/oct. Stereo Channels Low - 80Hz +/- 15dB Low Mid - 400Hz +/- 15dB High Mid - 3kHz +/- 15dB High - 12kHz +/- 15dB |
| Solo/Mute | SOLO / PFL MUTE |
| Channel Level Control | Fader |
| Trim/Gain Control | Rotary Pots |
| Phantom Power | +48V Phantom Power |
| Metering | Peak LEDs |
| Frequency Response | < 10Hz - 70kHz +0dB / -1dB < 10Hz - 130kHz +0dB / -3dB |
| Dynamic Range | Not Specified By Manufacturer |
| Signal-to-Noise Ratio | 110dB / 112dB A-weighted |
| Total Harmonic Distortion (THD) | 0.004% / 0.003% A-weighted |
| Power Supply | Power Consumption 50W Fuse (100 - 240V~, 50/60Hz) T 2.0 A H 250V Standard IEC Receptacle |
| Dimensions (WxHxD) | 3.9 x 26.9 x 16.1" (100 x 682 x 410mm) |
| Weight | 18.8 lbs (8.5kg) |
