- Inputs: 4x XLR / jack combination, 8x 6.3 mm jack
- Outputs: Main: 3-pin XLR (stereo), Aux: 2x 6.3 mm jack, Headphones: 6.3 mm jack
- Data: MIDI: In / Out, USB: for USB stick connection, LAN: Wifi Client / Acces Point, WiFi: integrated
- Input Channel: Gate, 4-band equalizer, compressor
- Output channel: 6-band equalizer, compressor, 31-band graphic equalizer FX processors: 4x Buses: 8x
- Dynamics/Effects:
- LA-2A: Compressor 1176LN, Compressor Fairchild 670: Compressor, EQ1, EQ5, Sub Octaver / Sub Bass Synthesizer, EX1 Stereo Modulation, Sound Maxer, Dimensional Chorus, Modulation Delay, Enhancer, Exciter, TruEQ/31-Band Equalizer, Vintage Room Reverb, Plate Reverb, 3-Tap Delay, Flanger & Delay, Wave Designer/Transient Editor, Stereo Precision Limiter, De-Esser, Chorus & Chamber.
- Compatibility: iOS, Android, Mac, Linux, PC
- Housing: Metal
The Behringer XR12 is a digital mixer in the form of a stagebox. It can be remotely controlled via the integrated router with Wi-Fi using external media devices such as tablets or PCs. All common system requirements such as iOS, Android, Mac and Linux are compatible.
Features
The XR 12 is equipped with 4 microphone inputs, which are combo jacks for XLR and jack. The microphone inputs are equipped with MIDAS preamplifiers, which are mainly characterized by their low noise. The other 8 inputs are jack sockets, to which both guitar, bass, keyboard, as well as MP3 players, as other line signals can be connected. A gate, a 4-band EQ and a compressor can be switched on per channel via the app.
Effects and connections
The DSP has an extensive collection of effects that can also be assigned to each channel. This also applies to the output channels, which are equally equipped with a compressor, a 6-band equalizer or with a 31-band graphic equalizer, in order to be able to optimally adjust the sound in difficult environments. The USB port allows a stereo signal to be recorded as well as the stereo sum to be played out for recording. A controller, such as the Behringer X Touch series, can be connected via the Midi interface, so that analog access via faders and pots for mixing is also possible. Included is the rugged XR12 with rack brackets to allow it to be rack mounted as well.
If you make music in a smaller formation, have sound reinforcement with voice applications, then you are very well advised with the XR 12.
Features:
- Manufacturer: Behringer
- Microphone Channels: 12
- Stereo Channels: 1
- Signal Processing: Digital
- Power Mixer: No
- Integrated Effects Processor: Yes
- AUX Channels: 2
- EQs: 4-Band
- Low Cut: Yes
- 19"-capable: No
- Phantom Power: Yes
- Integrated Power Adapter: Yes
- USB Input: Yes
- USB Output: No
- Talkback: No
- Symmetrical Outputs: Yes
- Integrated Audio Interface: No
- Parametric Mid EQ: Yes
- RJ45 Interface / Network: Yes
- APP control possible: Yes
- Weight (kg): 2.4
Tech Specs
- Digital
- 12
- 4 x XLR-1/4" combo
- Yes (activated via remote app)
- 6 x 1/4", 2 x 1/4" (Hi-Z)
- 2 x XLR
- Internal effects/processing inserts
- 2 x 1/4" TRS (aux bus out)
- Ethernet, Built-in Wi-Fi Module, 2-ch USB-to-device
- 1 x USB Type A (flash drive)
- Wi-Fi, Ethernet
- In/Out
- 1 x 1/4" TRS
- 100-band Real Time Analyzer (RTA)
- 4 stereo effects/modeling engines including delay, chorus, dynamics, Lexicon reverbs, flangers, exciters
- Yes
- 3.7"
- 5.9"
- 13.1"
- 5.3 lbs.
- 000-BI602-00010
