The Behringer STUDIO M Passive Studio Controller provides an all-in-one control over volume, source selection, and monitor switching. The passive circuitry ensures the purest signal path possible, along with high-quality input and output connectors guaranteeing pristine audio. The large volume knob makes precise level adjustments easy, while the Mono, Mute and Dim functions are super convenient time-saving tools. The perfect accessory for any home studio, or as part of a larger setup, the STUDIO M provides intuitive control right at your fingertips.
Full Description
Features
- All-in-one Master Volume controller, Source selector and Monitor switcher
- Active-free circuitry guarantees purest signal path
- Large Volume knob for extremely precise level adjustments
- Convenient Mono, Mute and Dim functions right at your fingertips
- 2 pairs of high-quality input connectors and 3.5 mm (1/8") stereo input perfectly connect to your DAW
- 2 pairs of high-quality outputs connectors to connect to your studio monitors
Specifications
Inputs
- Line inputs: 2 stereo
- Type: 4 x 1/4" TRS, balanced or unbalanced
- Alternative input B: 1 x 1/8" TRS, stereo
Outputs
- Line outputs: 2 stereo
- Type: 4 x 1/4" TRS, balanced or unbalanced
Controls
- Volume: 0 - 100%
- Playback controls: Mono, Mute, Dim
- Monitor select: A, B
- Source select: A, B
System
- Frequency response: 20 Hz to 20 kHz (±0.5 dB)
- Signal-to-noise ratio: Less than 90 dBu RMS, un-weighted
- Distortion (THD+N): Less than 0.01% @ 1 kHz, unity gain, 4 dBu input
- Crosstalk: Less than 60 dB @ 1 kHz, unity gain, 4 dBu input
Attenuation
- Muted: -100 dB
- Dim: 20 dB
Maximum Levels
- All inputs: +22 dBu
- All outputs: +15 dBu
