Type |
Active DSP-controlled full range loudspeaker |
|
Frequency Response(-10dB) |
42Hz-20kHz |
|
Horizontal Coverage |
90°/60° |
|
Vertical Coverage |
60°/90° |
|
Maximum Calculated SPL/1M (Continuous/Peak) |
128dB/134dB |
|
HF Driver |
Customized driver, 1.75” voice coil and 1.0”exit |
|
LF Driver |
Customized 12” driver, 3.0” voice coil |
|
DSP |
|
|
Processor |
48kHz signal sampling frequency,FIR filtering |
|
Presets |
MAIN,LF BOOST,W/SUB |
|
AMPLIFIER |
|
|
Amplifier Circuitry |
Class D |
|
Power (RMS standards) |
1100W |
|
Peak Power |
2200W |
|
Frequency Response(1W 8Ω 2ch) |
20Hz-20kHz(±0.5dB) |
|
Intermodulation Distortion |
＜0.05% |
|
Total Harmonic Distortion |
＜0.05% |
|
Cooling System |
Cooling with fans, air convection |
|
Protection |
DC protection, short circuit protection, overheat protection, input overload protection, output overload protection, soft startup protection, overvoltage protection, undervoltage protection |
|
Signal Input |
Female XLR(Mono jack 6.35) |
|
Signal Output |
Male XLR |
|
Power Input |
IEC power connector |
|
Working Voltage |
100-130V~ or 220-240V~ (±10%,50/60Hz） |
|
Power consumption (1/8 output power) |
95W |
|
CABINET |
|
|
Cabinet Material |
CNC machined plywood |
|
Coating |
Durable Polyurea Coating |
|
Cabinet Color |
Black is the default color. Contact Audiocenter for customization |
|
Grille |
Iron mesh |
|
Handles |
2 side |
|
Monitor Angle |
Symmetrical 45° monitoring Angle |
|
Hanging Hardwares |
M8 screw |
|
Pole Mount |
Base hole Φ35mm，0° or 10° options |
|
Speaker Dimension (W×H×D) |
355x599x349mm |
|
Carton Dimension (W×H×D) |
446×688×446mm |
|
Net Weight |
21.0kg |
|
Shipping Weight |
24.0kg |
