Type |
Active DSP controlled subwoofer |
|
Frequency Response(-10dB) |
32Hz-150Hz |
|
Maximum Calculated SPL/1M (Continuous/Peak) |
131dB/137dB |
|
LF |
Customized 1×18”driver, 4.0” voice coil |
|
DSP |
DSP |
|
Processor |
96kHz signal sampling frequency |
|
Presets |
80Hz,100Hz,120Hz |
|
AMPLIFIER |
AMPLIFIER |
|
Amplifier Circuitry |
Class D |
|
Power(RMS standards) |
1600W |
|
Peak Power |
3200W |
|
Frequency Response(1W 8Ω 2ch) |
20Hz-20kHz(±0.5dB) |
|
Intermodulation Distortion (20Hz-20kHz, half power) |
＜0.05% |
|
Total Harmonic Distortion (20Hz-20kHz,Rated power 8Ω) |
＜0.05% |
|
Cooling System |
Cooling with fans |
|
Protection |
DC protection, short circuit protection, overheat protection, input overload protection, output overload protection, soft startup protection, overvoltage protection, undervoltage protection |
|
Signal Input Connectors |
Female XLR |
|
Signal Output Connectors |
Male XLR |
|
Power Input Connectors |
Power connector |
|
Power Output Connectors |
Power connector |
|
Working Voltage |
100V-130V~ or 220V-240V~(±10%,50/60Hz) |
|
Power consumption (1/8 output power) |
149W |
|
CABINET |
|
|
Cabinet |
CNC made of excellent wood |
|
Cabinet Color |
Black is the default color. Contact Audiocenter for customization |
|
Grille |
Iron mesh |
|
Handles |
4 side |
|
Optional Accessories |
Flightcase with 100mm wheels / Durable rain bag/ Frame for flying and ground stacking/Dolly |
|
Pole Mount |
M20 base Φ35mm |
|
Speaker Dimension(W×H×D) |
590×639×800mm |
|
Carton Dimension(W×H×D) |
724×906×675mm |
|
Net Weight |
63.0kg |
|
Shipping Weight |
69.0kg |
|
Technical Support and After-sales Service |
Global application support team，EASE GLL files available |
